Morpholine Synthesis Catalysts Used In Industrial Devices

Description
Appearance: Black Cylinder Particle Size,mm: Φ(3.5-4)×(4-5)
Active Components: Co Crushing Strenght,N/particle ≥: 130
High Light:

Morpholine Synthesis Catalysts

Morpholine synthesis catalysts

MLS-10,which is morpholine synthesis catalysts uses the double transition metal as the main activity ,with the modified alumina as the carrier,added special promotor. It has been sucessfully used in many industrial devices. The catalyst has lots of advantages,such as high activity, good selectivity,flexible performance ,good stability.Service life of the catalyst can reach more than 28 months. And it takes less than 0.5kg catalyst to produce one-ton morpholine.

Physical and chemical properties

Item Index
Appearance Brown-black trilobe extrudates
Particle size (mm) ∮(2-3)×(3-15)
Crushing strength N/cm 100(min)
Bulk density kg/L 0.7-0.9
Content of active components % 20-30

Reference operating conditions



Process conditon



Pressure MPa Temperature ,℃ Space velocity hr-1
1.3-2.0 Beginning entrance : 207-210
Ending entrance : 225-230
0.09 - 0.13
Raw materials Diethylene glycol, ammonia hydrogen without any sulfur or sulfide
Diethylene glycol consumption 1.55(max), ensuring the recovery rate of morpholine no less than 97% in the process of seperation
Ammonia consumption 0.32(max), ensuring system sealed. Off-gas without ammonia, comsumption less with the ammonia recycled.
Hydrogen consumption 150NM3/ton

Packaging: Available in the barrels innerling plastic bags, net weight per drum of 40 kg. It also can be packaged according to requirements from users.
